Diamondback Release 29 1

Diamondback Release 29 1
  • Color: Russet Brown Matte
  • Color: Russet Brown Matte
$999.99
$2,549.99
Color: Russet Brown Matte
Size: Select size
Please select options Unavailable

Details

The Release 29 1 is a big-wheeled ripper made for long days and big lines. This aluminum 29er is built on the same 130mm-travel Level Link suspension platform as its smaller-wheeled siblings. We've adjusted the geometry for 29-inch wheels while keeping the same playful attitude of all our Level Link bikes. An SR Suntour Aion suspension fork and a Suntour Edge R rear shock soak up the rough stuff, while SRAM SX Eagle drivetrain components keep you cranking. Our Blanchard wheelset is tubeless compatible and comes with 2.3-inch-wide WTB Vigilante Comp tires for unwavering traction. When it's time to slow down, TRP Slate X2 hydraulic disc brakes keep you on your line all the way down the mountain.

Specs

Frame Release 29, 130mm Travel, Level Link Suspension Platform, Hydroformed Tubing, ISCG-05 Tabs, Boost 148x12mm Maxle Drop Out, 1.5" Tapered Headtube
Fork SR Suntour Aion 29", 140mm Travel, Air Spring w/Rebound Adjust, 35mm Stanction, 1.5" Aluminum Taper Steerer, 110x15mm Thru-axle
Rear Shock Suntour Edge R, 200x57mm, Rebound Adjust, 22.2mm Eyelet Width
Rims Diamondback Blanchard 28R, Tubeless ready, 32h
Spokes 14g Stainless Steel
Tires WTB Vigilante 29x2.3", Wire Bead
Bottom Bracket SRAM Powerspline, 118/73
Crankset SRAM SX w/Steel 32T Direct Mount
Shifters SRAM SX Eagle, 12 Speed
Rear Derailleur SRAM SX Eagle, 12 Speed
Cassette/Freewheel SRAM PG1210, 12 Speed, 11-50T
Chain SRAM SX Eagle, 12 Speed
Brakes TRP Slate X2, w/180mm Front / 180mm Rear Rotors
Brake Levers TRP Slate
Handlebars DB35 Aluminum 760mm Wide, 15mm Rise, 35mm Bar Bore
Tape/Grips DB Lock-On Grip
Stem DB35 Aluminum 35mm Reach, 35mm Bar Bore
Headset FSA No. 57 Sealed Cartridge
Seatpost TranzX YSP18JL, Internal Dropper, 31.6mm w/ 1x Remote
Saddle WTB Koda Comp
Pedals DB Aluminum Platform w/Replaceable Pins
Accessories & Extras Tool Kit, DB Shock Pump, DB Mud Guard, Spare RD Hanger

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Russet Brown Matte / Large 791964593157 02-0310191 210000016488
Russet Brown Matte / X-Large 791964593164 02-0310192 210000016489
