Diamondback Catch 1

Diamondback Catch 1
  • Color: Dark Teal Matte
  • Color: Dark Teal Matte
$1,499.99 - $2,549.99
Color: Dark Teal Matte
Size: Select size
Please select options Unavailable


"Adventure bikes" are often plodding beasts of burden that sacrifice thrills in the pursuit of extra stability. Well, where's the adventure in that? We went a different route entirely. By adding 2.8-inch-wide, plus-size tires to our Level Link suspension, we've created a bike that absolutely rips on tight trails, but does so with the extra grip and control of a plus-size bike. Voilà—adventure made awesome. We gave the Catch a slack-but-not-too-slack front end. We wanted control on fast descents, but we weren't willing to give up maneuverability on tight trails. A SRAM SX Eagle 12 speed drivetrain gives you the gearing to tackle any terrain, and TRP Slate X2 hydraulic disc brakes bring this machine to a tidy stop. If you're looking to tackle rough terrain and want the ultimate in control without sacrificing the thrill of riding, the Catch is your bike.


Frame Catch 27.5+, 130mm Travel, Level Link Suspension Platform, Hydroformed Tubing, ISCG-05 Tabs, Boost 148x12mm Maxle Drop Out, 1.5" Tapered Headtube
Fork SR Suntour Aion 27.5"+/29", 130mm Travel, Air Spring w/Rebound Adjust, 35mm Stanction, 1.5" Aluminum Taper Steerer, 110x15mm Thru-axle
Rear Shock Suntour Edge R, 200x57mm, Rebound Adjust, 22.2mm Eyelet Width
Rims Diamondback Blanchard 38R, Tubeless Ready, 32h
Spokes 14g Stainless Steel
Tires WTB Vigilante 27.5x2.8", Wire Bead
Bottom Bracket SRAM Powerspline, 118/73
Crankset SRAM SX w/Steel 32T Direct Mount
Shifters SRAM SX Eagle, 12 Speed
Rear Derailleur SRAM SX Eagle, 12 Speed
Cassette/Freewheel SRAM PG1210, 12 Speed, 11-50T
Chain SRAM SX Eagle, 12 Speed
Brakes TRP Slate X2, w/180mm Front / 180mm Rear Rotors
Brake Levers TRP Slate
Handlebars DB35 Aluminum 760mm Wide, 15mm Rise, 35mm Bar Bore
Tape/Grips DB Lock-On Grip
Stem DB35 Aluminum 35mm Reach, 35mm Bar Bore
Headset FSA No. 57, Sealed Cartridge
Seatpost Kindshock EXA Form 900i, Internal Dropper, 31.6mm w/1x Remote
Saddle WTB Koda Comp
Pedals DB Aluminum Platform w/ Replaceable Pins
Accessories & Extras Tool Kit, DB Shock Pump, DB Mud Guard, Spare RD Hanger

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Dark Teal Matte / Small 791964593263 02-0310113 210000021043
Dark Teal Matte / Medium 791964593270 02-0310114 210000021044
Dark Teal Matte / Large 791964593287 02-0310115 210000021045
Dark Teal Matte / X-Large 791964593294 02-0310116 210000018024
